Building Explosion Venting & Blast-Resistant Products
Active Venting + Passive Blast Resistance — Science-based Dual Protection Strategy
Explosion Venting & Blast Resistance
TKC offers explosion venting doors, windows, louvers, walls, roofs and ceilings, alongside blast-resistant doors, walls and windows. Explosion venting releases pressure; blast resistance is a separate protection strategy. Confirm FM 4440 scope and each product's test data against the relevant product and project documentation.
Explosion Venting Series — Active Protection
FM 4440-certified DLC explosion venting panels actively channel and dissipate explosion energy before structural damage occurs. Precision-calibrated trigger pressure ≤ 1.92 kPa, millisecond-level response.
Blast Resistance Series — Passive Protection
Engineered blast-resistant doors, windows, and wall systems that absorb and withstand explosion overpressure. Ideal for control rooms, safe havens, and critical equipment enclosures. Rated ≥300 kPa to ≥1,000 kPa.
Venting Product Series
Explosion Venting Door (TKC-XBM)
- Venting pressure ≤1.92 kPa
- Panel weight ~12 kg/m²
- Millisecond-level low-inertia response
- Dual function: venting + emergency escape
- FM 4440 system scope / FM DS 1-44 design reference
Explosion Venting Window
- Venting pressure ≤1.92 kPa
- Core: aluminum honeycomb / tempered glass
- Panel weight ~12 kg/m²
- Air L2 / Water L1 / Wind L4
- Confirm applicable scope in product and project documentation
Explosion Venting Louver (TKC-EVL)
- Venting pressure ≤1.92 kPa
- Standard opening 1000×1000 mm
- Aluminum louvers open continuously for ventilation
- Post-event: only replace venting screws
- Confirm applicable scope in product and project documentation
Explosion Venting Wall
- Venting pressure ≤1.92 kPa
- FM system weight ≤19.5 kg/m²
- National std weight ≤60 kg/m²
- Cable restraint break force ≥20 kN
- FM 4440 system scope / FM DS 1-44 design reference
Explosion Venting Roof
- Venting pressure ≤1.92 kPa
- FM system weight ≤14.6 kg/m²
- Cable φ6mm · 7×19 strand · 900mm
- Fastener break force 700N
- FM 4440 system scope / FM DS 1-44 design reference
Explosion Venting Ceiling
- Venting pressure ≤1.92 kPa
- FM system weight ≤14.6 kg/m²
- Device size 1000×1000 mm
- Cable SUS304 φ6mm
- For cleanrooms / data centers
Core Technical Components & Project Design References
TKC-01
Explosion Venting Fastener (Trigger Device)
TKC-JS900
Restraint Cable (Constraint Device)
Blast Resistance Product Series
Fire-Resistant Blast Wall / Ceiling
- CNAS-certified blast resistance ≥1000 kPa
- Fire resistance ≥4h (wall) / ≥2h (curtain wall)
- Sound insulation 51 dB
- Thermal 1.1 W/(m²·K)
- Patent panel ZL 202121527285.6 (23kg/sheet)
Fire-Resistant Blast Door
- CNAS-certified blast resistance ≥300 kPa
- Class A fire resistance 1.5h
- Air tightness L8
- Door closer durability ≥500,000 cycles
- Optional 400×400mm reinforced vision panel
Fire-Resistant Blast Rolling Door
- CNAS-certified blast resistance ≥1000 kPa
- Fire resistance 3h
- Explosion-proof motor Ex de IIB T4 Gb
- Standard size 3000×3000mm (customizable)
- For large-opening industrial facilities
Blast-Resistant Window (Daylighting)
- CNAS-certified blast resistance ≥300 kPa
- Air L8 / Water L6 / Wind L9
- Preserves natural daylighting and views
- For control rooms and laboratories
Blast-Resistant Coating (Polyurea)
- CNAS-certified blast resistance ≥300 kPa
- Max verified pressure 1.0 MPa
- Shock wave attenuation rate 98.4%
- Spray ≥3mm on blast-facing side
- For rapid retrofit of existing buildings
Venting Series Complete Technical Comparison
| Parameter | Venting Door (XBM) | Venting Window | Venting Louver (EVL) | Venting Wall | Venting Roof | Venting Ceiling |
|---|---|---|---|---|---|---|
| Venting Pressure | ≤ 1.92 kPa | ≤ 1.92 kPa | ≤ 1.92 kPa | ≤ 1.92 kPa | ≤ 1.92 kPa | ≤ 1.92 kPa |
| Core Material | Rock Wool | Al Honeycomb / Tempered Glass | Aluminum Louver Blades | Wall Panel + Purlins | Roof Panel + Purlins | Ceiling Panel + FFU Frame |
| FM Weight | ~12 kg/m² | ~12 kg/m² | — | ≤19.5 kg/m² | ≤14.6 kg/m² | ≤14.6 kg/m² |
| Air/Water Tightness | — | L2/L1 | — | — | — | — |
| Wind Resistance | — | L4 | — | — | — | — |
| Restraint Cable | — | — | — | TKC-JS900 ≥20kN | TKC-JS900 ≥20kN | TKC-JS900 |
| Fastener Break Force | 700 N | 700 N | 700 N | 700 N | 700 N | 700 N |
| Escape Function | ✓ | — | — | — | — | — |
| Ventilation Function | — | — | ✓ Always Open | — | — | — |
| Reference | FM 4440 system scope · 14J938 | Product/project documentation · 14J938 | Product/project documentation | FM 4440 system scope · FM DS 1-44 | FM 4440 system scope · FM DS 1-44 | FM 4440 system scope · FM DS 1-44 |
Qilu Petrochemical Olefin Plant Control Room Reinforcement Project
✓ After the explosion, the TKC-reinforced control room remained structurally intact and all operators were safely evacuated — zero casualties
Venting wall after explosion: panels opened to release pressure, structure intact
FM 4440 Certificate of Compliance
FM Approvals
Class 4440
Explosion Venting Washer Certification
Certified Products
TKC-01 & TKC-02 Explosion Venting Washers
Certified Company
Shanghai Tengxi Construction Engineering Co Ltd
Approval Identification
PR452429 / RR228240
Approval Granted
April 4, 2019 / June 2, 2021
Verify At
www.approvalguide.comFM 4440 is the international certification standard for building explosion venting washers. TKC-01 and TKC-02 Explosion Venting Washers are both FM 4440 certified, making them among the very few Chinese products globally to achieve this certification.
Start with a Free Safety Assessment
Speak with TKC's certified engineers for a systematic evaluation of your explosion protection and firestop systems against FM Global standards. We serve clients across China and Asia.
